伯尔梅特 消防系统

型号: FP 450-80 400 系列

工作原理
FANCYIND
FANCYIND
FANCYIND FP 450-80 型阀门由导阀控制，配有可调式 3 通高度导阀。导阀通过连接到蓄水池底部某静止点的导管[1]来感应蓄水池水位静压力。
The Model FP 450-80 is a pilot controlled valve equipped with an adjustable, 3-way, altitude pilot. The pilot senses the

static head of the reservoir level via a tube [1] connected to a “still point” at the bottom of the reservoir.
静压力升高超过导阀设置值时，导阀[2]使压力通过球阀[4]进入上控制腔[3]，主阀关闭。
Should static head rise to pilot setting, the pilot [2] applies pressure to the control chamber [3] via cock valve [4],
powering the main valve to shut.
静压力低于导阀设置水位约 1 米时，压力排出上控制腔，主阀全开。
Should static head fall below pilot setting by approximately 1m (3 ft), the pilot vents the control chamber, causing the
利用 3 通球阀[4]可手动关闭主阀。
main valve to fully open.
对于 8”及更大尺寸的阀门，增配加速器[5]可以加快阀门反应速度。
The 3-way cock valve [4] enables manual closing of the main valve.

For 8” valves and larger, an accelerator [5] quickens valve response.

尺寸范围: 1½”-6” 尺寸范围: 8”-12”

FANCYIND FANCYIND FANCYIND

技术规格

该款液位控制阀在预先设置的高水位时关闭，水位大约下降一米时全开，主阀上安装的 3 通高度导阀可感应水位下降。
The Level Control Valve shall shut at pre-set high reservoir level and fully open in response to an approximately
one-meter (three-foot) level drop, as sensed by the 3-way altitude pilot mounted on the main valve.
主阀：阀门为球型或角型阀体，阀体内具有弹性隔膜组件。阀门流道无阻隔，无阀杆导向或支承杆。阀体阀盖材质为球墨铸铁。所
Main Valve: The main valve shall be an elastomeric type globe (or angle) valve with a rolling-diaphragm. The valve shall
有外部螺栓和螺母采用 316 不锈钢材料。阀门所有零部件都可在线维修更换，无需将阀门从管道上拆除。
have an unobstructed flow path, with no stem guide or supporting ribs. The body and cover shall be ductile iron. All
驱动：阀门动作由一体化隔膜组件完成。隔膜组件包括全支撑平衡式模压隔膜和内衬加强型硬化阀盘，阀盘采用径向密封。隔膜组
external bolts and nuts shall be of Stainless Steel 316. All valve components shall be accessible and serviceable
FANCYIND 件是仅有的移动部件。 FANCYIND FANCYIND
without removing the valve from the pipeline.
Actuation: Valve actuation shall be accomplished by a fully peripherally supported, one-piece balanced

控制系统：控制系统由 3 通高度导阀（具有弹簧和 8” (200 mm)隔膜）、隔离球阀、3 通球阀和过滤器组成。所有接头都是不锈钢材
rolling-diaphragm, vulcanized with a rugged radial seal disk. The diaphragm assembly shall be the only moving part.
质。装配完成的阀门经过水力测试。
Control System: The control system shall consist of a 3-way, altitude pilot valve with a covered, centered spring

and 8” (200 mm) sensing diaphragm, (for 10” and larger valves, an accelerator shall be added), an isolating cock valve,
质量保障：阀门制造厂通过 ISO 9000 和 ISO 9001 质量认证标准认证。
a 3-way cock valve, and a filter. All fittings shall be of stainless steel. The assembled valve shall be hydraulically tested.
Quality Assurance: The valve manufacturer shall be certified according to the
ISO 9000 and 9001 Quality Assurance Standard.
