伯尔梅特 消防系统

型号: FP 450-66 400 系列

工作原理
FANCYIND
FANCYIND FP 450-66 型阀门由浮球控制，配有 4 通双液位导阀组件，阀门可保持上次最终位置。浮球[1]可沿着竖杆[2]滑动。浮球在到达可
FANCYIND
The Model FP 450-66 is a float controlled valve equipped with a 4-way, “last position”, bi-level float pilot assembly.
The float [1] slides along the rod [2]. When the float reaches either the adjustable high [3] or low [4] level stoppers, it
调式高水位挡块[3]或低水位挡块[4]时，拉动或推动竖杆组件，起着切换浮球导阀[5]位置的作用。浮球在挡块之间时，主阀处于上
either pulls the rod assembly down or pushes it up, switching the float pilot [5] position. When the float is between the
次最终位置。
adjustable stoppers, the main valve remains in its last position.
在高水位时，浮球导阀使压力进入控制腔[6]，主阀关闭。
At high level, the float pilot applies pressure to the control chamber [6], powerfully shutting off the main valve.
在低水位时，浮球导阀使控制腔压力排出，主阀开启。
At low level, the float pilot vents the control chamber, powerfully opening the main valve.
对于 8”及更大尺寸的阀门，增配加速器[7]可以加快阀门反应速度。
For 8” valves and larger, an accelerator [7] quickens valve response.

尺寸范围: 1½"-6" 尺寸范围: 8"-12"

FANCYIND FANCYIND FANCYIND

技术规格

该款液位控制阀可在预先设置的蓄水池低水位时开启，在预先设置的高水位时关闭。
The Level Control Valve shall hydraulically open at pre-set low level, and shut at pre-set high level.
Main Valve: The main valve shall be an elastomeric type globe (or angle) valve with a rolling-diaphragm. The valve shall
主阀：阀门为球型或角型阀体，阀体内具有弹性隔膜组件。阀门流道无阻隔，无阀杆导向或支承杆。阀体阀盖材质为球墨铸铁。所有外
have an unobstructed flow path, with no stem guide or supporting ribs. The body and cover shall be ductile iron. All
部螺栓和螺母采用 316 不锈钢材料。阀门所有零部件都可在线维修更换，无需将阀门从管道上拆除。
external bolts and nuts shall be of stainless steel 316. All valve components shall be accessible and serviceable
驱动：阀门动作由一体化隔膜组件完成。隔膜组件包括全支撑平衡式模压隔膜和内衬加强型硬化阀盘，阀盘采用径向密封。隔膜组件是
without removing the valve from the pipeline.
FANCYIND 质量保障：阀门制造厂通过 ISO 9000 和 ISO 9001 质量认证标准认证。 FANCYIND
FANCYIND
仅有的移动部件。
Actuation: Valve actuation shall be accomplished by a fully peripherally supported, one-piece balanced
rolling-diaphragm, vulcanized with a rugged radial seal disk. The diaphragm assembly shall be the only moving part.
Quality Assurance: The valve manufacturer shall be certified according to the

ISO 9000 and 9001 Quality Assurance Standard.
