            伯尔梅特  消防系统


               型号:  FP 430-59                                                                      400 系列


            典型安装
 FANCYIND       系统组件            FANCYIND                                                FANCYIND

            System Components
            1 - 伯尔梅特 FP 430-59 型阀门
            1 - BERMAD Model  FP 430-59
            2 - 消防泵
            2 - Fire Pump
            3 - 止回阀
            3 - Check Valve
            4 - 压力表
              4 - Pressure Gauge







                                                          2

                                                                       4


                                                                                   3

 FANCYIND                  1    FANCYIND                                                FANCYIND














            安装注意事项

            ■  阀门尺寸不得小于 NFPA-20 规定尺寸。
            ■     Valve size should be no less than NFPA-20 requirements.
            ■  阀门周围应预留足够空间以便进行维护,确保驱动装置方便拆卸。
            ■     Provide  adequate clearance around valve for maintenance, ensuring that  the  actuator can  be  easily  removed.
            ■  安装时阀盖朝上,以便阀门设计性能达到最佳。
            ■     Design  installation with the  valve  cover  up  for best performance.
            ■  阀门安装前,请使用大流量水流冲洗管道。
              ■     Ensure that  before the valve  is installed, pipeline  is flushed  at  full flow.
