描述
The Det-Tronics® SmokeWatch™ U5015 Explosion Proof Smoke Detector has Division and Zone explosion-proof ratings and is suitable for industrial and commercial applications. The SmokeWatch smoke detector is designed to operate effectively with smoldering and rapidly growing fres and contains the ability to annunciate fault ensuring no undisclosed failures. The U5015 Smoke Detector outputs include 0-20 mA, a localized LED, and relays.
迪创的防爆烟感U5015是可以用在商业和工业应用的防爆型烟感。这种烟感适合是用在火灾燃烧迅速而且被及时发现的场合。U5015具备LED状态显示灯，也可同通过4-20mA和继电器输出信号。
The hot-swappable sensor module is intrinsically safe and allows live maintenance while under power, without de-classifying the hazardous area. The integrated junction box is available in a variety of port confgurations for simplifed wiring and installation.
热插拔的传感器模块是本安型的，可以无需考虑防爆区域等级在带电情况下进行更换。配套的接线盒有多种数量和规格的接口供选择。
产品特点
- FM Approved for use in Class I, Division 1, and Zone 1 hazardous locations/ FM认证，用于1区
- IECEx/ FM Approved for smoke detection performance/ FM认证性能保证
- Trouble-free photoelectric operation/ 可靠的光电技术
- 0-20 mA output for DCS integration/ 4-20mA 模拟量信号输出到DSC或PLC
- Self-checking circuitry ensures reliable smoke detection/ 线路自检功能
- Alarm, Auxiliary, and Fault relays for controlling annunciation devices or fire panel interface/ 报警，输出联动等控制功能
- LED provides a visual indication that an alarm has occurred/ LED可视灯可判断监测/报警状态
- IP44 ingress protection level suitable for onshore or offshore requirements/ IP44 防护等级
应用环境
– Combustible storage facilities/ 易燃物仓库
– Munitions manufacturing/ 军品制造
– Volatile chemical storage/ 挥发性化学品仓库
– Chemical processing plants/ 化工厂
– Petroleum refineries/ 炼油厂
– Turbine enclosures/ 燃气轮机组
– Battery rooms
– HVAC applications
技术特征
- Ideally suited for classified areas in the petrochemical, oil, and gas industry/ 适合于石油化工，油气等工业领域
- DCS, PLC, integration with milliamp, or relay outputs/ 模拟量信号/继电器信号兼容于DCS或PLC
- Rugged design for environmental extremes/ 对于极端环境的设计
- Visual conformation of detector alarm/ 可视的报警信号
- Detects smoldering fres/ 可检测阴燃火
- No undisclosed failures/ 线路的自我检测功能
参数表/外形尺寸
[pdfjs-viewer url=”http%3A%2F%2Fwww.fancyind.com%2Fwp-content%2Fuploads%2Fwoocommerce_uploads%2F2018%2F03%2F95-8752-1.1-Q5016_DUCT.pdf” viewer_width=100% viewer_height=1360px fullscreen=true download=false print=true]
防爆隔爆型烟感U5015
1、货源稳定 上海幻点为Det-Tronics授权经销商，所有货源质量保证
2、关于价格 网页标注价格为订货价格，实际价格请跟我们联系确认。可以开具增值税发票。
3、关于售后 依照Det-Tronics原厂的质保条款。 现场服务费不包含在产品价格里面。
